不同的用途与简单/Brief Introduction：

该机械组为10-20ml液状体液液状体分装生產的线中的通常机械。是由洗瓶、烘箱二合一机和分装封膜二合一机所构造，能自動成功液状体液瓶的洗瓶、烘箱、分装和封膜等行动，是液状体液生產的制造厂家更自然的配建机械，几乎适用GMP耍求。It’s a major equipment in production line for oral filling, it main used in filling, capping placing and sealing of 10-20ml bottles. Tracking filling, cap automatically conveying by electromagnetic oscillator, automatic sealing , no bottle no filling. Filling and sealing integrated in one machine, advanced design, compact structure and completely comply with requirement of GMP

优缺点/Characteristic：

◆装量精准度，制止滴漏问题。罐装精准性强。High filling accuracy.◆变频器无级控速，制作加车速能调，可选择择与众不同的制作加车速。Frequency control, production speed is adjustable, you can choose a different production rate.◆很多电气产品构件均用到进口商有名气企业。All electrical components are imported famous brands.◆重新凸显计数器功能键。Automatically countting function.◆控制所采用日本的三凌PLC，抗骚扰，办公平衡。Controlled by Mitsubishi PLC◆使用性能安全，系统维护护理更方便。Stable performance, easy maintenance.◆整个设备形象所采用了SUS304不锈铝打造、与原材料接处方面所采用了316L铝合金。整个设备已经按GMP条件装修设计。Outer material is 304 stainless steel, and the material of filling part is 316L stainless steel. The machine is completely designed according to GMP requirements.

方法叁数/technical parameters：

适用于规格尺寸/Bottle size	10-20ml
产生能力素质/Capacity	60-90瓶/半小时/60-90bottles/min
烤干温差/Dryer tempreture	100-300°
造纸废水处理河水量/Water wastage	0.5m3/h
过滤水耗量/Purifying water consumption	0.3m3/h
装量精确/Filling precision	≤1%
电源模块/Voltage	380V/50Hz
电功率/Power	33KW
产生线总长/Dimension	3500×1500×1600mm
