种类与详细资料/Brief Introduction：

机器是结合在一起补血内服液液窗有机玻璃罐子的新产品上市设备，全面满足了所报补血内服液液窗有机玻璃罐子的不合理视觉效果。此灌封机使用的氟塑料饮料瓶，显然不所需洗瓶机、干燥机，更不所需进行消毒，能够 直接的灌封。这个机器全系统自动理瓶、进瓶、分装，分装量可靠，无漏滴，无瓶不分装。上盖、封好率led光通量100%。此机技术水平较为先进，体积计算小、进行可靠、噪音低，运营检修、洗便于等特别，根本包含GMP标淮。This machine is a new product instead of oral liquid bottles, thoroughly solved before the adverse effect of oral liquid glass bottle. The used plastic bottles, filling and sealing machine not only don't need to bottle washer, dryer, more don't need disinfection, can be directly potting. The machine is fully automatic unscramble bottle, bottle feeding, filling, filling volume stability, no LouDi, no bottle no filling. Cover and sealing rate can reach 100%. This machine technology is advanced, small volume, stable running, low noise, convenient operation and maintenance, cleaning, etc, in full compliance with GMP standard.注：本规格型号有低速档和绕城高速两者生产产量供您选。Note: this model has two kinds of low speed and high-speed production for your choice.

优势特点 Characteristic

◆该机常应用在各式各样易折瓶服用液计量检定灌装设备和封膜。The machine is suitable for all kinds of folding bottles of oral liquid filling and sealing of measurement.◆全部电子元器件元器件均使用闻名店牌。All electrical components adopt famous brand◆该设备运作直接便捷，无瓶不灌装设备，检定*。It has intuitive and convenient operation, no bottle no filling, measuring precision.◆易折塑瓶灌封机的主耍结构设计与机理Easy to fold the main structure and principle of plastic bottle filling and sealing machine◆NFGFY型服食液易折塑料材质瓶灌封机重要理瓶器、理盖器、主链传动控制系统、同部带摩擦送罐平衡部件、空罐检漏平衡部件、灌装设备企业、消除平衡部件、热溶封企业、气动平衡自动化机械指尖夹瓶企业、步进驱动器高压电机摩擦上瓶企业与出瓶企业等组建。Type NFGFY oral liquid is easy to fold the plastic bottle filling and sealing machine main GaiQi bottle opener, and the main transmission system, the synchronous belt clearance to send bottle device, empty bottle leak detection device, filling body, eliminating device, hot melt sealing mechanism, pneumatic mechanical fingers bottle gap on the bottle structure, servo motor and a bottle of institutions, etc.◆机械适用的冲剂液易折朔胶瓶、盖就是一定干净干燥区制作的，应当药袋材经营执照证，故而瓶身与底盖经交换和"去开发"后可真接来到灌封间。用理盖器、理瓶器的自行定向委培分配归置，删去反相底盖及瓶身底口朝下的瓶，使定向委培分配后的包材喂料有规责地来到输送机在轨道中。Machine using oral liquid is easy to fold the plastic bottles, cover a certain production of clean area, should have the medicine packaging material license, so the bottle and the bottom cover after transfer and "outsourcing" can go directly into the potting. By Richard GaiQi, automatic directional arrangement of bottle opener, eliminate reverse bottom cover and the bottom of the bottle mouth bottle at the bottom, after making the orientation of packaging material feeding regularly into orbit. ◆定位后液体液易折氟塑料瓶子在卸料导轨总排名Directional oral liquid after folding plastic bottles in conveying rail out easily

科技基本参数technical parameters：

型号model	NLGFY-40	NLGFY-80
装量的范围The load range	5-100ML
生产能力production capacity	20-40瓶/分	50-80瓶/分
塑封率Hot sealing intensity	》99%
装量误差率The load error	《1.5%
破埙率damage rate	《1.0%
瓦数power	2KW	3KW
主机电源Power Supply	380V 50Hz/220V 50Hz
外形尺寸boundary dimension	2700*1100*1900mm	3000*1480*1900mm
权重 Weight	700Kg	800Kg
