领域与简洁/Brief Introduction：

全主动液压泵式膏体酱装罐机是俺子公司融入市厂需求量开发设计的新类产品。这个机器选取SUS304不锈钢圆管液压泵式剂量泵制定装罐，且集主动上盖、主动旋盖、汽车电器电为一体机，第三产业运用，拆迁赔偿绿地面积小，大范围运用于生物制药、商品、农药杀菌剂、化工类、美妆品等这个行业的液體打包，合乎GMP标准规范必须。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

作用/characteristic：

◆采取柱塞泵式计量检验泵施行装罐，使用几种黏黏度粘液，精密度较高；泵的空间结构采取快接式拆除构造，有助除污、消毒杀菌。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆齿轮泵式计量检验泵活赛环质量依据产业及药液组分的多种选取硅硅胶，四氟氯乙烯或其余质量，非常规场所，选取工业陶瓷质量。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC把控状况，变频式可控硅调压，智能化限度高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不分装，系统自动数值功能模块。Lack of bottle filling, automatic counting function◆装量改变便捷，可是一次改变所有的计量检验检定泵的充填量，也可重视有几个计量检验检定泵做微幅改变；操控简变，改变迅猛。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆包装针头拥有防滴漏问题安装，充填时入侵瓶底包装，迟滞升高，以防止气泡图片。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆整套装置可支持各种规格为的玻璃瓶，优化简变，可在短期间内搞定。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆整个设备按GMP需求装修设计。The machine designed according to the requirements of GMP

技术水平基本参数/technic parameter：

适宜水瓶座产品规格Size of bottles	20-1000ml（选择标准生产厂家）20-1000 - ml (according to your need）
适宜瓶里直径为Apply the bottle diameter	¢20-¢150mm
适宜盖子规模Apply the lid specifications	¢20-¢70mm
研发作用 production capacity	四头装罐：1000-2500瓶/个钟头 Four filling head: 1000-2500 bottles per hour 八头灌装线：2500-4000瓶/个钟头 Eight head filling: 2500-4000 bottles per hour 12头灌装设备：4000-6000瓶/一小时 12 head filling: 4000-6000 bottles per hour
装量误差度The load error	±1%
旋盖及格率Screw cover percent of pass	≥99%
主机电源power supply	380V，50HZ
效率power	3.0KW
供气gas sources	0.4-0.75MPA
速率把控好speed control	变频器调压variable speed
